ZB1970LED Mini Stainless steel camera with connector

New product

Quotation

The new ZB1970LED is a compact Full HD video camera with a waterproof connector at the back.

IP68 and manufactured in Stainless Steel 304, the ZB1970LED offers a clear image in HD-TVI format (AHD/CVI/Analogue CVBS on request).

More details

Description

Mini bullet SST video camera ZB-1970LED

The ZB1970LED is an IP68 mini camera with a built-in 2Mp Sony sensor which allows a video resolution in 1920x1080.

Thanks to its waterproof connector you can stock it safely.

The 9 Hi-Power leds are intensity controlled using our LUMISS monitors series.

The video signal is on HD-TVI as default but you can ask AHD, CVI or CVBS PAL (optionnal).

Extension cables are sold separately (Order number: RALL20U for 20meters and RALL50U for 50m)



Technical specifications

  • SONY 2Mp video sensor
  • IP68 EN60529
  • Illumination by 9 High power white leds
  • 1080p
  • Pixels 1920x1080
  • Lens 3,6 mm (90° in air)
  • IP68 EN60529
  • Illumination by 9 High power white leds
  • 1080p
  • Pixels 1920x1080
  • Lens 3,6 mm (90° in air)
  • Minimum illumination 0,001 Lux color / 0.0001Lux monochrome
  • Power voltage 12 V
  • Max power consumption 100mA@ 12V
  • Temperature range -20° ~ +6
  • Cable lenght  50cm default, up to 100m (20, 50,100m)
  • Diam. Ø 29.5 mm x 68mm
  • Diam. Ø 29.5 mm x 68mm
