DS-2TD8167-230ZG2FL/W PTZ Long range Bi-Spectrum camera

Image Sensor: Vanadium Oxide Uncooled Focal Plane Arrays
Resolution: 640 × 512 (the resolution of output image is 1920 × 1080)
Pixel Interval: 17 μm
Response Waveband: 8 μm to 14 μm
NETD: Less than 35 mK (@25 °C,F#=1.0)
Focal Length: 23 to 230 mm
Focus Mode: Semi-auto & Manual
IFOV: 0.74 to 0.07 mrad
Aperture: F0.9 to F1.5
Field Of View: 26.61° × 21.43° (H × V) to 2.83° × 2.27° (H × V)
Min. Focusing Distance: 2m
Digital Zoom: ×2, ×4, ×8
Optical Module: Image Sensor
1/1.8" Progressive Scan CMOS: Resolution
1920 × 1080, 2 MP
Min. Illumination :Color: 0.005 Lux @ (F3.5, AGC ON), B/W: 0.0005 Lux @ (F3.5, AGC ON)
Field Of View: 24.33° × 13.83° (H × V) to 0.41°× 0.23° (H × V)
Focal Length: 16.7-1000 mm, 60x
Aperture (Range): F3.5 to F8.8
Focus Mode: Semi-auto/Manual
Digital Zoom: ×2, ×4, ×8, ×16
Shutter Speed: 1s to 1/30,000s
WDR: 120 dB
Optical Defog: Yes
Image Effect: Picture In Picture
Display partial image of thermal channel on the full screen of optical channel
Target Coloration: Supported in white hot and black hot mode
PTZ: Movement Range
Pan: 360° Continuous Rotate; Tilt: From -45° to + 45° (auto flip)
Pan Speed: Configurable, From 0.01°/s to 40°/s, Preset Speed: 240°/s
Tilt Speed :Configurable, From 0.01°/s to 20°/s, Preset Speed: 200°/s
Proportional Zoom: Yes
Presets: 300 in total, 273 are configurable.
Patrol Scan: 8; Up to 32 Presets Per Patrol
Pattern Scan: 4; More Than 10 Minutes Per Pattern
Power Off Memory: Yes
Park: Preset/Pattern Scan/Patrol Scan/Auto Scan/Tilt Scan/Random Scan/Frame Scan/Panorama Scan: PT Status
Turn On/Turn Off: Scheduled Task
Preset/Pattern Scan/Patrol Scan/Auto Scan/Tilt Scan/Random Scan/Frame Scan/Panorama Scan/Doom Reboot/Doom Adjust/Aux Output
Smart Function :VCA
Support 4 VCA rule types (Line Crossing, Intrusion, Region Entrance, and Region Exiting), up to 10 scenes and 8 VCA rules for each scene
Temperature Measurement
Support 3 temperature measurement rule types, 273 presets as scene, 21 rules of each scene (10 points, 10 areas, and 1 line)
Temperature Range: -20 °C to 150 °C (-4 °F to 302 °F)
Temperature Accuracy:± 8 °C (±14.4 °F)
Fire Detection: Dynamic fire point detection, up to 10 fire points detectable.

Main Stream
Optical channel:
50 Hz:25 fps (1920 × 1080, 1280 × 960, 1280 × 720)
60 Hz:30 fps (1920 × 1080, 1280 × 960, 1280 × 720)

Thermal channel:
50 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 512, 384 × 288)

Sub-Stream
Optical channel
50 Hz:25 fps (704 × 576, 352 × 288)
60 Hz: 30 fps (704 × 576, 352 × 288)

Thermal channel
50 fps (704 × 576, 640 × 512, 384 × 288)

Video Compression:
Main stream: H.265+/H.265/H.264+/ H.264
Sub-stream: H.265/H.264/MJPEG

Audio Compression:
G .711u/G.711a/G.722.1/MP2L2/G.726/PCM

Network Protocols
IPv4/IPv6, HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP, UDP, IGMP, ICMP, DHCP, PPPoE
Network Storage
MicroSD/SDHC/SDXC card (up to 256 G) local storage, and NAS (NFS, SMB/CIFS), auto network replenishment (ANR)
API
ISAPI, HIKVISION SDK, third-party management platform, ONVIF (Profile S, Profile G, Profile T)
Simultaneous Live View
Up to 20 channels
User/Host Level
Up to 32 users, 3 levels: Administrator, Operator, User
Security
User authentication (ID and password), MAC address binding, HTTPS encryption, IEEE 802.1x access control, IP address filtering
Client
iVMS-4200, Hik-Connect
Web Browser
Live view (plug-in allowed) : Internet Explorer 11
Live view (plug-in free) : Chrome 57.0 +, Firefox 52.0 +
Local service : Chrome 57.0+, Firefox 52.0 +

Interface: Alarm Input
7-ch inputs (0-5 VDC)
Alarm Output
2-ch relay outputs, alarm response actions configurable
Alarm Action
Preset/Patrol Scan/Pattern Scan/SD Card Record/Relay Output/Smart capture/FTP upload/Email linkage
Audio Input
1, 3.5 mm Mic in/Line in interface. Line input: 2 - 2.4 V [p-p], output impedance: 1 KΩ ± 10%
Audio Output
Linear Level; Impedance: 600 Ω
Communication Interface
1, RJ45 10 M/100 M Self-adaptive Ethernet interface.

1, RS-485 interface

Analog Video Output: 1.0 V [p-p]/75 Ω, BNC for thermal channel
General
Web Client Language: 32 languages

Alimentation: 48 VDC ± 20%, two-core terminal block
Power Consumption: 48 VDC, 5 A, max. 220 W
Work Temperature/Humidity: From -40°C to 65°C (-40°F to 149°F); Humidity: 95% or Less
Wiper: Yes
Protection Level: IP66 Standard; TVS 6000V Lightning Protection, Surge Protection and Voltage Transient Protection
Dimension: 649.2 mm × 438 mm × 668.3 mm (25.6 " × 17.2 " × 26.3 ")
Weight: Approx. 60kg (132.3 lb)
*Product performance is based on testing in a controlled environment. Your results may vary due to several external and environmental factors.

Warranty 5 Years
