Pan Tilt Units - Heavy Duty - Motorized There are 5 products.
ALLWAN SECURITY
AL620PTU - Motorized Turret 6Kg / 10Kg
Motorized turret for camera, high quality, no maintenance. Aluminium fusion. Power supply 12VDC or 24VDC (to specify). Waterproof IP 68 according to EN60529.
ALLWAN SECURITY
AL615PTU - Motorized Turret 16Kg / 25Kg
Motorized turret for camera. High quality, no maintenance. Aluminium fusion. Power supply 12VDC or 24VDC (to specify). Waterproof IP 68 according to EN60529.
ALLWAN SECURITY
AL635PTU - Motorized turret 20Kg / 50Kg
Motorized turret for camera High quality, no maintenance. Aluminium fusion 12VDC, 24VDC or 230VAC (to be specified). Waterproof IP 68 according to EN60529.
ALLWAN SECURITY
AL650PTURX - Heavy load 50Kg motorized pan tilt
Heavy-Duty Motorized Turret The AL650PTURX series is available in two payload versions: 50 kg and 80 kg. This rotating turret is equipped with a slip ring, allowing endless 360° rotation. Designed for heavy loads, it can be used in industrial environments, both indoors and outdoors.
ALLWAN SECURITY
250PTE - Motorized turret AISI316L
Reinforced Stainless Steel Motorized Pan/Tilt unit 100% stainless steel 316L, maximum load capacity of 25 kg, and IP66/67 waterproof rating according to EN60529.
Pan Tilt Head Motorized : Durability and Precision for Professional Applications
The range of Pan & Tilt motorized units offered by Allwan stands out for its robust design, precise positioning, and reliability in demanding industrial environments. These devices are engineered to provide smooth and dependable orientation of surveillance cameras, tailored to the most rigorous professional applications.
Outdoor Pan Tilt Heads - Design and Materials
Allwan PT turrets ensure optimal resistance to extreme weather conditions, corrosion, and harsh industrial settings. The 316L stainless steel models are particularly suited for marine or chemical environments, offering IP66/67 sealing according to the EN60529 standard.
Pan Tilt Platform - Load Capacity and Rotation
The range covers a wide load spectrum, from 6 kg for compact 2-axis motorized turret models like the AL620PTU, up to 250 kg for heavy-duty models such as the AL6250PTURX. Some turret models can rotate continuously 360° horizontally without stops, thanks to integrated slip rings. Vertical tilt varies by model, providing orientation flexibility adapted to specific surveillance needs.
Pan Tilt Positioner - Control and Protocols
Allwan turrets are compatible with various control protocols, including Pelco-D, Pelco-P, RS485, RS232, and TOR. They offer variable rotation speeds, enabling precise positioning tailored to the requirements of each application. Advanced features such as preset positioning, automatic scanning, and position feedback management are available on some models, offering enhanced flexibility in camera control.
Pelco Pan Tilt - Professional Applications
These motorized PTU are ideal for a variety of professional uses, including industrial monitoring, port security, sensitive site surveillance, as well as law enforcement and marine environments (depending on the model). They are designed to withstand the harshest conditions, delivering reliable and durable performance.
Allwan’s Pan & Tilt motorized turrets represent a high-quality solution combining robustness, precision, and flexibility, meeting the demands of discerning professionals in industrial and outdoor environments.
