VVDS-6500: 2-Channel HD Video Multiplexer Over a Single Coaxial Cable

Description

The VDS6500 is a coaxial video modem kit compatible with AHD, TVI, CVI, and CVBS formats. It transmits 2 video signals and 2 DC12V power supplies through a single coaxial cable. It also supports UTC control over the same cable. This system allows for resolutions up to 1080P.

Only the receiver (monitor side) requires an external power supply, which is included.

Technical Specifications

• Transmits 2 video signals and 2 DC12V power supplies over a single coaxial cable
• Real-time transmission up to 500 meters
• Kit includes one transmitter, one receiver, and a power supply
• LED indicators on both units for link status
• Supports UTC (Up the Coax) control
• Transmitter video input: CVI / TVI / AHD and CVBS
• Receiver video output: CVI / TVI / AHD and CVBS
• DC output power from transmitter: DC12V, 3A (for 2 cameras)
• Current consumption (without cameras): 250mA
• Polarity protection: Yes
• Supported cable types: RG59, RG6, RG11, 5C-2V, 3C-2V
• Operating temperature: -10°C to +45°C, 10%–70% humidity
• Storage temperature: -25°C to +75°C, 0%–95% humidity
• Dimensions: 100 (L) x 75 (W) x 25 (H) mm

Transmitter Specs (6500-R)

• DC12V output capacity: 36W (3.0A)
• Video input level: 1.0 Vpp at 75 ohms
• Dimensions (L x W x H): 100 x 75 x 25 mm
• Weight: 280 g

Receiver Specs (6500-L)

• Power supply: 48VDC (included)
• Video signal bandwidth: 45 MHz
• Video output level: 1.0 Vpp at 75 ohms
• Dimensions (L x W x H): 100 x 75 x 25 mm
• Weight: 220 g
