This product is no longer in stock
Image Sensor: CMOS Progressive Scan 1 / 1.8 "
Signaling system: PAL / NTSC
Min. Illumination: Color: 0.002 Lux @ (F1.2, AGC ON), 0 Lux with IR
Shutter time: 1 s to 1 / 100,000 s
Slow shutter: yes
Lens: 2.8 to 12 mm and 8 to 32 mm, optional
Adjustment range: Support, pan: 0 ° to 355 °, inclination from 0 ° to 90 °, rotation: 0 ° to 360 °
Day and night: IR filter
Wide dynamic range: 140dB
Focus: automatic, semi-automatic, manual
Video compression: H.265 + / H.265 / H.264 + / H.264 / MJPEG
H.264 Code Profile: Basic Profile / Main Profile / High Profile
Video bit rate: 32Kbps ~ 16Mbps
Max. Image Resolution: 1920 x 1080
Frame rate: 50Hz: 50fps (1920 × 1080, 1280 × 960, 1280 × 720)
60Hz: 60fps (1920 × 1080, 1280 × 960, 1280 × 720)
Sub-stream: 50Hz: 25fps (704 × 576, 640 × 480)
60Hz: 30fps (704 × 480, 640 × 480)
Third stream: 50Hz: 25fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 480)
60Hz: 30fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 480, 640 × 480)
Image Enhancement: BLC, HLC, DNR 3D, Defog, EIS
Picture Settings: Rotation, Saturation, Brightness, Contrast, Sharpness, AGC, and White Balance Adjustable with Client Software or Web Browser
Targeted culture: yes
BLC-HLC Support - Smart Defog: Support EIS - DNR 3D
Overlay of images: the LOGO image can be overlaid on a video format 128 × 128 24 bit bmp
Day / night switch: day / night / auto / time / alarm triggered
Network Storage: Supports local storage on microSD / SDHC / SDXC (256 GB) and NAS (NFS, SMB / CIFS), ANR
Alarm Trigger: Motion Detection, Video Violation Alarm, Disconnected Network, IP Address Conflict, Illegal Connection, Hard Disk Full, Hard Disk Error
Protocols: TCP / IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Hello
General function: key reset, anti-flicker, five streams and up to 5 custom streams, heartbeat, password protection, privacy mask, watermark, IP address filter
System Compatibility: ONVIF (PROFILE S, PROFILE G), ISAPI, SDK
Behavioral analysis: crossing of lines, intrusion, entry of region, exit of region. Support for triggering alarms by specified target types (human and vehicle). Suppression of erroneous alarms caused by target types such as leaf, light, animal and flag, etc.
Face Capture: Face Detection Performance: Up to 30 Faces per Image
Detectable Face Position: ͗ Supports left and right oscillations from -65 ° to 65 °, tilt up and down from -45 ° to 45 °
IR range: 2.8 to 12 mm: up to 50 m; 8 to 32 mm: up to 100 m
Humidity 95% or less (without condensation)
Power supply: 12 V DC ± 20%, PoE
Impact protection: IK10
Proof of time: IP67
Dimensions: Camera: 144 × 347 mm (Φ5,7" × 13,7")
With packaging: 405 × 190 × 180 mm
Weight: Camera: approx. 2.45 kg
Optional: motorized lens.
ANPR Camera - Vega Smart HD - 2HDNew generation ITS systems. Covers two lanes with a maximum width of 7.5 meters. Detects vehicles at a maximum speed of 250 km / h. Distance up to 25 meters. Capture and processing of images triggered by an Ethernet command. Additional features can be Added.
Vega Smart Speed 3D multi-tracking radar. Advanced system for detecting speed violations. New tool to fight speeders! Continuous monitoring up to two lanes. Maximum distance of 7.5 meters. Features a lightweight camera and capturing 75 frames per second.Detects and controls vehicles at a maximum speed of 250 km / h.
ANPR Mobile - Camera megapixel color and monochrome sensors, infrared light.Installed on specialized operational service cars. Support for surveillance and road protection. Scans up to one hundred license plates / second. At the front and the back, whatever the lighting conditions, it remains efficient for reading moving plates.
Vega Basic - ANPR Camera. Full HD sensor for reading reflective and non-reflective plates. Speed detected from 70 km / h to 150 km / h. Working distance from 8 meters to 25 meters. Enter up to 60 frames per second. Autonomous thanks to the local buffering of information. Easy to install and does not require external infrared lighting.
