Camera Features:
Image Sensor: CMOS Progressive Scan 1 / 1.8 "
Signaling system: PAL / NTSC
Min. Illumination: Color: 0.002 Lux @ (F1.2, AGC ON), 0 Lux with IR
Shutter time: 1 s to 1 / 100,000 s
Slow shutter: yes
Lens: 2.8 to 12 mm and 8 to 32 mm, optional
Adjustment range: Support, pan: 0 ° to 355 °, inclination from 0 ° to 90 °, rotation: 0 ° to 360 °
Day and night: IR filter
Wide dynamic range: 140dB
Focus: automatic, semi-automatic, manual
Video compression: H.265 + / H.265 / H.264 + / H.264 / MJPEG
H.264 Code Profile: Basic Profile / Main Profile / High Profile
Video bit rate: 32Kbps ~ 16Mbps
Image features:
Max. Image Resolution: 1920 x 1080
Frame rate: 50Hz: 50fps (1920 × 1080, 1280 × 960, 1280 × 720)
60Hz: 60fps (1920 × 1080, 1280 × 960, 1280 × 720)
Sub-stream: 50Hz: 25fps (704 × 576, 640 × 480)
60Hz: 30fps (704 × 480, 640 × 480)
Third stream: 50Hz: 25fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 480)
60Hz: 30fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 480, 640 × 480)
Image Enhancement: BLC, HLC, DNR 3D, Defog, EIS
Picture Settings: Rotation, Saturation, Brightness, Contrast, Sharpness, AGC, and White Balance Adjustable with Client Software or Web Browser
Targeted culture: yes
BLC-HLC Support - Smart Defog: Support EIS - DNR 3D
Overlay of images: the LOGO image can be overlaid on a video format 128 × 128 24 bit bmp
Day / night switch: day / night / auto / time / alarm triggered
Network Features:
Network Storage: Supports local storage on microSD / SDHC / SDXC (256 GB) and NAS (NFS, SMB / CIFS), ANR
Alarm Trigger: Motion Detection, Video Violation Alarm, Disconnected Network, IP Address Conflict, Illegal Connection, Hard Disk Full, Hard Disk Error
Protocols: TCP / IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Hello
General function: key reset, anti-flicker, five streams and up to 5 custom streams, heartbeat, password protection, privacy mask, watermark, IP address filter
System Compatibility: ONVIF (PROFILE S, PROFILE G), ISAPI, SDK
Smart Features:
Behavioral analysis: crossing of lines, intrusion, entry of region, exit of region. Support for triggering alarms by specified target types (human and vehicle). Suppression of erroneous alarms caused by target types such as leaf, light, animal and flag, etc.
Face Capture: Face Detection Performance: Up to 30 Faces per Image
Detectable Face Position: ͗ Supports left and right oscillations from -65 ° to 65 °, tilt up and down from -45 ° to 45 °
General features:
IR range: 2.8 to 12 mm: up to 50 m; 8 to 32 mm: up to 100 m
Humidity 95% or less (without condensation)
Power supply: 12 V DC ± 20%, PoE
Impact protection: IK10
Proof of time: IP67
Dimensions: Camera: 144 × 347 mm (Φ5,7" × 13,7")
With packaging: 405 × 190 × 180 mm
Weight: Camera: approx. 2.45 kg
Optional: motorized lens.
