LYNX1600 Camera de surveillance très longue distance étanche IP67/IP68
New product
The LYNX1600 is a revolutionary camera designed for unparalleled long-range imaging, ideal for military personnel and various tactical operations.
Featuring a wide 40mm to 1600mm telephoto lens, expandable to 3200mm with digital zoom, it captures fast-moving targets with ultra-fast autofocus. Equip yourself with the LYNX1600 for superior surveillance, security, and inspection capabilities, ensuring mission preparation and precision.
LYNX1600 Stabilized IP67 Long-Range Surveillance System
The 40x zoom (40-1600mm) allows you to observe objects even a few kilometers away. Since stability and heat flicker play an important role at this great distance, the system offers several other important features. The integrated optical image stabilizer guarantees a blur-free image, even at great distances and in windy conditions. Thanks to its high light sensitivity, it is possible to capture color images with little noise, even in the dark. The LYNX800 series is ideally suited for many police tasks. It allows for effective surveillance and security at borders, forests, airports, ports, and other public places.
40x optical zoom
The SX1600 is equipped with a 40x optical zoom lens that covers a broad range of focal lengths from 20mm on the wide angle end to 800mm on the telephoto end. It is complemented with 1.25x digital zoom to achieve long-range surveillance equivalent to 2000m in focal length.
20mm to 800mm
High-performance image stabilization
New image stabilization system
The SX1600 combines optical image stabilization (OIS) and electronic image stabilization (EIS) to accurately compensate for camera shake, typically caused by gusts and footing vibrations at the site of camera installation. The system is particularly effective when shooting in the ultra-telephoto range, which is susceptible to even the slightest of shakes.
Without image stabilization With image stabilization
High-performance EIS
In the EIS mode, the SX1600 uses a sensor large enough for its lens’s effective diameter to secure full HD resolution (1920 x 1080), thereby delivering footage of premium quality. The combined use with OIS also improves the durability of the image stabilization system substantially.
Full HD（1920×1080）
Recording area
General sensor SX800's sensor
Use of new devices
The SX1600 sports high-precision gyro sensors to accurately detect minute vibrations that could not be detected previously. The use of newly-developed high-thrust linear motor delivers an advanced level of accuracy and tracking performance.
High-speed AF system
On-sensor phase detection AF
The on-sensor phase detection AF uses phase detection pixels across the sensor to instantaneously measure distance according to the displacement of incident lights. The SX800 also offers “contrast AF,” which detects areas of high contrast in images at high accuracy, and automatically switches to the optimum AF setting.
- 1. Micro lens
- 2. Color filter
- 3. Phase detection filter
- 4. Phase detection pixels
- 5. Photo diode
Rear Focus mechanism
The use of the Rear Focus mechanism has significantly reduced the weight of the focusing lens group. This has also dramatically increased the focus drive speed to enable “continuous AF.” Users can choose between “Continuous AF,” “Quick AF” and “Manual Focus” according to the conditions where the camera is used.
Image processing technology
Low light conditions
The use of the highly sensitive sensor and the effect of advanced noise reduction mean the SX800 can shoot clear footage with minimal noise even in low light conditions.
ISO 400 ISO 204800
Fog reduction
The SX1600 uses a unique imaging technology to bring vivid clarity to hazy images caused by light diffusion with airborne mist droplets and dust.
Fog reduction OFF Fog reduction ON
Heat Haze reduction
The SX1600 uses a unique image processing technology to reduce the shimmering effect of heat haze, caused by large difference in atmospheric temperatures, to make the entire images easier to see.
Simplified setup
Cameras with built-in lens
Conventional surveillance systems require the adjustment of optical axis and flange focal length when mounting a lens on a camera. The SX1600, which carries a built-in lens, is shipped with such settings optimally adjusted to bring out maximum performance. The design also eliminates the need for complicated wiring, thereby significantly reducing man-hours at the time of installation.
Specifications LYNX1600:
Optical Zoom: 40x
Digital Zoom: 1.25x, 1.5x, 1.75x, 2x
Focal Length: 40mm - 1600mm
Maximum Aperture Ratio: 1:8 (W), 1:14.8 (T)
Minimum Object Distance (MOD) to the front lens:
10m (40 - 800mm focal length)
20m (801 - 1600mm focal length)
Angle of View [16:9 (H x V)]: W: 21.0° x 11.9° T: 0.27° x 0.15°
