SMART-SWITCH Controller input / Output 16 Way WEB/SMS/RC

New product

Quotation

SMART-SWITCH GSM + IP Plug & Play

This switch was developed to remotely control the activation of remote cameras wit SmartBatLi12xx.
It is an extension of the Smart battery from Allwan security.

More details

uses the proprietary communication bus allowing the interconnection of the batteries. Each channel is configurable on the web interface of the energy case (smartBLi12) If the battery has an SMS extension (SB-GSM), it is also possible to remotely control each channel and to know the status. These functions are also available in the wireless remote control menu (SB-RC02). 2 digital inputs to connect external sensors 2 digital outputs for activating peripherals (alarm, wipers, fans ...)

BAT-GPIO – Remote controller intelligent position

Alimentation

12V DC

Input

XLR3 Male with bus communication

Output 12V

8 x XT60 Or Jack 2.1mm

Output Digital

2 (terminal blocks plug 3Way)

Input Digital

2 (terminal blocks plug 3Way)

Indicator ON/OFF

LEDs

Activation LED

ON/OFF Web interface

Working Temperature

- 21 °C to 55 °C

Alimentation

12V DC

Curent max /output

3A

Total max output

10A

Dimensions

135X 100X40 mm

Cable

1m XLR3 Male to XLR3 Female

Warranty

2 years
